To work out the min/max Solidor overall height:
Add the slab, head, threshold and cill dimensions from this table
Option | Large frame | Slim frame | Aluminium | Residence Radlington |
---|---|---|---|---|
Head options | 57mm | 37mm | ||
Threshold options | 57mm | 37mm | 20mm | |
Cill options | 30mm | 55mm |
Minimum / Maximum Solidor sizes44mm GRP standard door slabs, sidepanels and glass dimensions
Slab Name | Min Slab width | Min Slab width w-rim pull | Max Slab width | Min Slab height | Max Slab height | MIN Sidepanel width | Max Sidepanel width | glass sizes | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Traditional | ||||||||||||||||
Alnwick | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 558 x 1219 | ||||||||
Beeston | 740 | 760 | 910 | 1850 | 2060 | 300 | 460 | 558 x 914 | ||||||||
Berkley | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 203 x 152 | ||||||||
Conway | 740 | 760 | 910 | 1850 | 2060 | 300 | 460 | 549 x 250 (+Radius), 203 x 609 (x2) | ||||||||
Edinburgh | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 203 x 1219 | ||||||||
Harlech | 740 | 760 | 910 | 1850 | 2060 | 300 | 460 | 203 x 914 | ||||||||
London | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 558 x 254 | ||||||||
Ludlow | 740 | 760 | 910 | 1850 | 2060 | 300 | 460 | 203 x 914 | ||||||||
Nottingham | 740 | 760 | 910 | 1850 | 2060 | 300 | 460 | 203 x 914 | ||||||||
Sterling | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 558 x 583 | ||||||||
Stafford | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 558 x 914 | ||||||||
Thornbury | 600 | 600 | 910 | 1850 | 2060 | 147 | 910 | No Glass | ||||||||
Tenby | 740 | 760 | 910 | 1850 | 2060 | 300 | 460 | 203 x 152 (x2), 203 x 609 (x2) | ||||||||
Windsor Solid | 740 | 740 | 910 | 1850 | 2060 | 740 | 910 | No Glass | ||||||||
Flint | ||||||||||||||||
Flint Solid | 600 | 600 | 910 | 1850 | 2060 | 147 | 910 | No Glass | ||||||||
Flint 1 | 600 | 600 | 910 | 1850 | 2060 | 410 | 910 | 190 x 190 | ||||||||
Flint 2 | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 190 x 470 | ||||||||
Flint 3 | 600 | 600 | 910 | 1850 | 2060 | 410 | 910 | 190 x 190 | ||||||||
Flint 4 | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 203 x 914 | ||||||||
Flint 5 | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 203 x 1219 | ||||||||
Flint Square | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 190 x 190 | ||||||||
Italia | ||||||||||||||||
Amalfi | 600 | 600 | 910 | 1850 | 2060 | 310 | 910 | 177 x 1625 | ||||||||
Ancona | 600 | 600 | 910 | 1850 | 2060 | 147 | 910 | 190 x 470 | ||||||||
Ancona Solid | 600 | 600 | 910 | 1850 | 2060 | 147 | 910 | No Glass | ||||||||
Biella | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 508 x 1625 | ||||||||
Bologna | 600 | 600 | 910 | 1850 | 2060 | 410 | 910 | 190 x 190 | ||||||||
Brescia | 740 | 760 | 910 | 1850 | 2060 | 450 | 910 | 177 x 1625 | ||||||||
Garda | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 203 x 914, 203 x 609 | ||||||||
Genoa | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 190 x 190 (x2), 203 x 609 | ||||||||
Messina | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 190 x 190 (x2), 203 x 914 | ||||||||
Milano | 740 | 760 | 910 | 1850 | 2060 | 720 | 910 | 190 x 190 | ||||||||
Modena | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 190 x 190 | ||||||||
Monza | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 203 x 1219 | ||||||||
Naples | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 190 x 190 | ||||||||
Palermo | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | No Glass | ||||||||
Parma | 600 | 600 | 910 | 1850 | 2060 | 310 | 910 | 190 x 190 | ||||||||
Pisa | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 549 x 250 | ||||||||
Rimini | 740 | 760 | 910 | 1940 | 2060 | 310 | 910 | 190 x 190 (x2), 203 x 1219 | ||||||||
Roma | 600 | 600 | 910 | 1850 | 2060 | 410 | 910 | 190 x 190 | ||||||||
Siena | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 549 x 250 | ||||||||
Sorrento | 740 | 820 | 910 | 1850 | 2060 | 740 | 910 | 609 x 203 | ||||||||
Trieste | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 558 x 583 | ||||||||
Turin | 600 | 600 | 910 | 1850 | 2060 | 300 | 910 | 203 x 914 | ||||||||
Venice | 740 | 760 | 910 | 1850 | 2060 | 740 | 910 | 177 x 1625 | ||||||||
Verona | 600 | 600 | 910 | 1850 | 2060 | 147 | 910 | No Glass | ||||||||
Slab name | Range | Midrail | Bottom | Min Width* | Min Height* | Knocker/Spy Avil | Knocker/SpyHole | Measurement | ||||||||
Thornbury | Traditional | Yes as Standard | Yes as Standard | Yes | From bottom of Slab | 1493 | ||||||||||
Ludlow | Traditional | Yes as Standard | As Special | 1940 | Yes | From bottom of Slab | 1493 | |||||||||
Beeston | Traditional | Yes as Standard | As Special | 1940 | No | |||||||||||
Conway | Traditional | Yes as Standard | As Special | 1940 | Yes | From Top of Slab | 613 | |||||||||
Harlech | Traditional | Yes as Standard | As Special | 1940 | Yes | From bottom of Slab | 1493 | |||||||||
Nottingham | Traditional | Yes as Standard | As Special | 1940 | Yes | From bottom of Slab | 1493 | |||||||||
Stafford | Traditional | Yes as Standard | As Special | 1940 | No | |||||||||||
Tenby | Traditional | Yes as Standard | As Special | 1940 | Yes | From bottom of Slab | 1493 | |||||||||
Edinburgh | Traditional | Yes as Standard | As Special | 2000 | Yes | From bottom of Slab | 1493 | |||||||||
Berkley | Traditional | Yes as Standard | As Special | 2000 | Yes | From bottom of Slab | 1493 | |||||||||
Alnwick | Traditional | Yes as Standard | As Special | 2000 | Yes | From bottom of Slab | 1493 | |||||||||
London | Traditional | Yes as Standard | As Special | 2000 | Yes | From Top of Slab | 556mm if slab under 1949. 613mm if slab over 1949mm | |||||||||
Windsor Solid | Traditional | 5th Rung Up | 1st Rung Up | Yes | Specification Needs Checking | |||||||||||
Sterling | Traditional | Yes as Standard | No | No | ||||||||||||
Flint Solid | Flint | Yes as Standard | Yes as Standard | Yes | From bottom of Slab | 1493 | ||||||||||
Flint 1 | Flint | Yes as Standard | Yes as Standard | Yes | Supplied Loose | |||||||||||
Flint 2 | Flint | Yes as Standard | Yes as Standard | Yes | Supplied Loose | |||||||||||
Flint 3 | Flint | No | Yes as Standard | 1770 | No | |||||||||||
Flint 4 | Flint | No | Yes as Standard | No | ||||||||||||
Flint 5 | Flint | Yes as Standard | Yes as Standard | No | ||||||||||||
Flint Square | Flint | Yes as Standard | Yes as Standard | Yes | Yes | Supplied Loose | ||||||||||
Bologna | Italia | No | Yes as Standard | Yes | Yes | Supplied Loose | ||||||||||
Genoa | Italia | No | Yes as Standard | No | ||||||||||||
Roma | Italia | No | Yes as Standard | No | ||||||||||||
Naples | Italia | Yes as Standard | Yes as Standard | No | ||||||||||||
Turin | Italia | Yes as Standard | Yes as Standard | No | ||||||||||||
Ancona | Italia | Yes as Standard | Yes as Standard | Yes | Supplied Loose | |||||||||||
Pisa | Italia | Yes as Standard | Yes as Standard | No | ||||||||||||
Verona | Italia | Yes as Standard | Yes as Standard | Yes | From bottom of Slab | 1493 | ||||||||||
Ancona Solid | Italia | Yes as Standard | Yes as Standard | Yes | From bottom of Slab | 1493 | ||||||||||
Siena | Italia | Yes as Standard | Yes as Standard | Yes | From bottom of Slab | 1493 | ||||||||||
Garda | Italia | No | Yes as Standard | Yes | From bottom of Slab | 1493 | ||||||||||
Monza | Italia | Yes as Standard | No | |||||||||||||
Palermo | Italia | 5th Rung Up | 1st Rung Up | Yes | Specification Needs Checking | |||||||||||
Milano | Italia | No | As Special | 800 | 1900 | Yes | From bottom of Slab | 1493 | ||||||||
Brescia | Italia | No | As Special | 800 | 1960 | Yes | From bottom of Slab | 1493 | ||||||||
Parma | Italia | No | As Special | 1900 | No | |||||||||||
Amalfi | Italia | No | As Special | 1960 | No | |||||||||||
Biella | Italia | No | As Special | 2000 | No | |||||||||||
Venice | Italia | No | As Special | 2000 | Yes | From bottom of Slab | 1493 | |||||||||
Sorrento | Italia | As Special | As Special | 2000 | No | |||||||||||
Modena | Italia | No | As Special | 800 | 1960 | Yes | Supplied Loose | |||||||||
Messina | Italia | No | As Special | 800 | 1800 | Yes | From bottom of Slab | 1493 | ||||||||
Trieste | Italia | Yes as Standard | No | No | ||||||||||||
Rimini | Italia | No | As Special | 800 | Yes | Supplied Loose | ||||||||||
Abstract | n | n | n | n | ||||||||||||
Brilliante | n | n | ||||||||||||||
Bullseye | ||||||||||||||||
Caladonian Rose | n | n | n | n | n | n | ||||||||||
CFT 2.1/2 | n | |||||||||||||||
Clarity - Gold Only | n | n | n | |||||||||||||
Clear/Black Star | ||||||||||||||||
CRL 2.1 | n | |||||||||||||||
CRL 2.3 | n | |||||||||||||||
CSB 5.1 FT | n | |||||||||||||||
CTB 17.1/17.2 | n | n | ||||||||||||||
CTB 18.1 | ||||||||||||||||
CTB 19.1/19.2 | n | n | ||||||||||||||
CTB12.3 BG | n | |||||||||||||||
CTB12.3 Clear | n | |||||||||||||||
CTL 31.2B | n | n | ||||||||||||||
CTL 6.1 | n | |||||||||||||||
Diamond B&W | n | n | n | |||||||||||||
Diamond Black | n | n | n | |||||||||||||
Diamond Butterscotch | n | n | n | |||||||||||||
Diamond Red | n | n | n | |||||||||||||
Dorchester | n | n | n | n | n | |||||||||||
Elegance | n | n | n | n | n | |||||||||||
Etch Square | n | |||||||||||||||
Fairmont | n | n | ||||||||||||||
Gaumont | n | n | ||||||||||||||
Jewel | n | n | ||||||||||||||
Linear | n | |||||||||||||||
London Etch | n | |||||||||||||||
Matrix | n | |||||||||||||||
Modena | n | n | n | |||||||||||||
Oceanic | n | n | ||||||||||||||
Paramount | n | n | ||||||||||||||
Park Lane Bespoke | n | n | n | n | n | |||||||||||
Potomac | n | n | n | |||||||||||||
Prairie | n | n | n | n | n | |||||||||||
Quad Black | n | n | n | n | ||||||||||||
Quad Blue | n | n | n | n | ||||||||||||
Quad Grey | n | n | n | n | ||||||||||||
Quad Red | n | n | n | n | ||||||||||||
Reflections | n | n | n | n | n | |||||||||||
Royale | n | n | ||||||||||||||
Simplicity | n | n | n | n | n | |||||||||||
Tate | n | n | ||||||||||||||
Trio Squ Black | n | n | n | n | ||||||||||||
Trio Squ Blue | n | n | n | n | ||||||||||||
Trio Squ Grey | n | n | n | n | ||||||||||||
Trio Squ Red | n | n | n | n | ||||||||||||
Trio Square (Sea Green/Green) | ||||||||||||||||
Trio Square ButterScotch | ||||||||||||||||
Victorian | n | |||||||||||||||
Vogue | n | n | ||||||||||||||
Wiltern | n | n | ||||||||||||||
Zinc Art Star | n | n | n | n | n | |||||||||||
Abstract | n | n | n | |||||||||||||
Brilliante | n | |||||||||||||||
Bullseye | n | |||||||||||||||
Caladonian rose | ||||||||||||||||
Clarity - Gold Only | n | |||||||||||||||
Clear/black star | ||||||||||||||||
Crl 2.1 | ||||||||||||||||
Crl 2.3 | ||||||||||||||||
CSB 5.1 FT | ||||||||||||||||
CTB 17.1 | n | |||||||||||||||
Ctb 17.2 | ||||||||||||||||
Ctb 18.1 | ||||||||||||||||
CTB 19.1 | n | |||||||||||||||
Ctb 19.2 | ||||||||||||||||
CTB12.1 | ||||||||||||||||
CTB12.3 BG | ||||||||||||||||
CTB12.3 Clear | ||||||||||||||||
CTF 2.2 | ||||||||||||||||
CTL 31.2B | ||||||||||||||||
CTL 6.1 | ||||||||||||||||
Diamond B&W | n | |||||||||||||||
Diamond Black | n | |||||||||||||||
Diamond Butterscotch | n | |||||||||||||||
Diamond Red | n | |||||||||||||||
Dorchester | ||||||||||||||||
Elegance | n | |||||||||||||||
Fairmont | n | |||||||||||||||
Gaumont | n | |||||||||||||||
Jewel | n | |||||||||||||||
Linear | n | n | ||||||||||||||
London etch | ||||||||||||||||
Matrix | n | n | ||||||||||||||
Modena | ||||||||||||||||
Oceanic | n | |||||||||||||||
Paramount | n | |||||||||||||||
Park lane | ||||||||||||||||
Potomac | n | n | n | n | ||||||||||||
Prairie | n | |||||||||||||||
Quad Black | n | |||||||||||||||
Quad Blue | n | |||||||||||||||
Quad Grey | n | |||||||||||||||
Quad Red | n | |||||||||||||||
Reflections | n | |||||||||||||||
Royale | n | |||||||||||||||
Simplicity | n | |||||||||||||||
Tate | n | |||||||||||||||
Trio sq butterscotch | ||||||||||||||||
Trio sq sea green | n | |||||||||||||||
Trio squ black | n | |||||||||||||||
Trio squ ble | n | |||||||||||||||
Trio squ grey | n | |||||||||||||||
Trio squ red | n | |||||||||||||||
Victorian | ||||||||||||||||
Vogue | n | |||||||||||||||
Wiltern | n | |||||||||||||||
Wish stick | n | |||||||||||||||
Zinc art star |
Overall glass thickness: 28mm (toughened)
